Quick Details:
Name: USB2.0 Optical fiber Printer Inkjet Board. Nozzle model: Epson DX5.
Color channel: 8 channels/8 colors. Number of nozzles: 1440.
Ignition frequency: 30KHz. Trolley speed: 1.2M/S.
Data interface: The 1.25G optical fiber is connected to the spray car board, and the USB2.0 cable is connected to the computer.
Nozzle features: Can print water-based, thermal transfer, paint, eco-solvent, UV and other inks.
Nozzle protection: Nozzle reverse connection protection, stimulating nozzle (flash spray), short circuit protection.
Board support: Single head, double head, three head, four head, eight head, sixteen head, thirty-two head.
Function support: Anti-collision and continuous printing, automatic height measurement, variable point printing, device power failure and continuous printing, USB automatic reset, USB disconnection and continuous printing, paper out detection, ink stack self-check, etc.
Application machine:
White ink scald transfer machine,Photo machine,UV flatbed machine,Double-station direct printing machine, etc.
The Photo machine prints the colorful patterns on the special materials with the printheads. It is generally used in advertising, graphics, and CAD industries. It has high precision and long life of the printhead. The photo machine solves the shortcomings of gray color and high machine purchase cost, And it can make a variety of inks for users, such as indoor and outdoor, widely used in many industries.
Features of UV printing solution: easy to use and operate, no plate making and repeated color registration process, easy to operate and maintain. The use of environmentally friendly UV ink, spray and dry, stable printing, bright colors, high curing strength, low curing energy, environmental protection and no odor. The use of varnish can enhance the brightness effect of the image surface, and the adhesion of varnish on the surface of the image can also protect the image to a certain extent.
UV printing application materials: a wide range of UV printing printing materials, flexible media such as: time stamp, PVC, reflective film, canvas, carpet, leather, etc.; rigid media such as: glass, ceramic tiles, metal, ceiling, aluminum, wood, door, acrylic Board, plexiglass board, foam board, corrugated cardboard, etc.
Application scenario:
Wood printing Glass printing Leather printing
